Customized 45KL 50KL fresh milk tanker semitrailer stainless steel material for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer of milk truck, milk tank, fresh milk delivery tank, liquid food tank truck, liquid food tank semitrailer, milk storage tank semitrailer, etc. With many years’experience in manufacturing and selling, Chengli Special Automobile Co., Ltd. could design and manufacture 2cbm mini milk tank, 3-6cbm milk tank truck, 7-25 milk truck, 30-45cbm milk tank semitrailer, 1000-2500 gallon milk truck and liquid food truck, 6500 gallon milk tank semitrailer and 10000gallon milk tank semitrailer, etc.etc. More information, please feel free to contact with us.
The material of the milk tank truck adopts high uqlaity 304 food grade stainless steel and alinumum alloy, etc. And the milk tank could install insulation or cooling device, transporting fresh milk, liquid foods, etc. And there will be several components of the tank, loading different mediums, etc.
Product name | Fresh milk tanker trailer for sale | Overall dimension(L*W*H) | 12600×2500×3850 |
volume | 45000L | Tanker dimension(L*W*H | 12240*2480*2110 |
Rated mass | 31800 | Curb mass | 8200kg |
Compartments | 4 compartments evenly | Tanker shape | Oval horizontal |
Tanker material | SUS304-2B foodgrade | Inner shell thickness | δ3.0 mm |
Exterior cover thickness | δ1.0mm | Outlet diameter | ∮51mm |
Insulation material | 70 mm Polyurethane-coating +10mm Rubber and plastic insulation cotton | Thermal insulation | polyurethane spray foaming, insulation performance 24 hours not more than 2 °C
|
Tanker head-end | Single-layer butterfly head 3㎜ thickness | Cleaning way | CIP automatic cleaning, each bin equipped with cleaning ball, to meet the requirements of 360 ° cleaning |
Chassis | Triple FUWA axles, 16T braking pads, 12R22.5*12 tires with steel wheel rim,aluminum Alloy legs, aluminum side protection, aluminum fender, aluminum rear protection; | ||
Remark | 1. The milk release switch and cleaning switch are made into cluster structure, and each milk warehouse number is marked. The transport medium and the volume of the announcement are sprayed on the tank before the whole vehicle leaves the factory. | ||
Fresh milk transport vehicle modification configuration: the tank structure is divided into three layers: insulation layer, insulation layer and tank body.
One. The body of the frame can be made of food grade 304 material stainless steel plate, and the tank body can be made into 2-3 cabins. The tank body requires smooth and no acute angle. A cip (cleaning device) tank is provided in each milk tank with a washer.
Second, the middle of the tank is an insulation layer, which has a heat preservation effect to prevent deterioration of fresh milk. The temperature change does not exceed 1 degree for 24 hours at a temperature difference of 30 degrees. The insulation material is insulated with 80 (mm) thick polyurethane foam material.
Third, the outer layer of the tank (protective layer of the insulation layer) is made of 2mm thick 304L stainless steel. The outer skin and trunk of stainless steel are beautiful in appearance, the whole body is beautiful in appearance, scientific in structure, light in weight and good in strength.
4. Each single warehouse has a separate discharge port (self-flow port) and a feed port (can port).
5. Optional chiller, rock wool insulation, exhaust gas circulation heating, and stainless steel pump to make the vehicle have a suction function.
3 axles milk semitrailer is with the overall dimension(L*W*H) of 12600×2500×3850, adopts 13ton fuhua axles, 12 sets of 11.00R20 rail tyre, 28ton outriggers, with ABS, etc.
This time the Mongolia customer jut order 3 axles 45cbm milk semitrailer. And there are five components of the tank semitrailer, the outer layer with insulation layer to avoid the fresh milk going bad. The inner tanker is polished by the special equipment, and making sure no milk hanging. The inner tanker is smooth, non sharp angle, etc. There is CIP(cleaning device) installed for the five rooms.
There are three layers of the milk semi-trailer, the inner tanker is manufactured by 5mm thick 304/2B food grade stainless steel; the middle is 80mm PU foam insulation layer, and 60mm PU foam of the manhole part, the temperature will be changed one degree within 24 hours; the exterior of the tanker is 1.2mm thick 304 stainless steel mirror panel.
The inner tanker has cleaning device, cleaning rod(cleaning ball), cleaning pipe(with the diameter of 38mm), turntable cleaning sprayer, etc. Automatically cleaning when with water source.
More information, please feel free to contact with Ms. Anita Deng. The hot sale line is 0086 13329899995.
