high quality and best price 50cbm bulk feed container semitrailer for sale

Overall dimension(L*W*H): 12000×2550×3950（mm ）(approximate)

28T  single-action  outriggers,  90#  tractor  pin,   12R22.5   12PR  tires,   steel  spring suspension, 3 axles.

A, Bulk feed container material: 5mm thickness aluminum alloy ellipse shape, 8mm thickness secondary beam,feed inlet dimension: 900X900.

B, Volume: 50cubic meters.

C, compartments: 5 compartments

D,  discharging  way:  hydraulic   system   discharging,  multi-way  valve,  DENISON hydraulic pump, EATON motor, 75KW diesel engine, radiation installed, 220Liters volume hydraulic oil tanker, 200Liters volume diesel tanker.

E, length of auger: 8m length

F, paint color: white color, the company logo free to paint.

G, retrofitting: pneumatic switch box for feed outlet.

The bulk feed container adopts high quality 5mm thickness aluminum alloy ellipse shape tanker welded, 8mm thickness secondary beam, 50cubic meters volume. There are 5 independent compartments.

Working  principle ：  hydraulic  system  discharging,  hydraulically  controlled  the feeding auger lifting up-down or flatting and rotating ±180° . Easy discharging. The bulk feed container color: white color; the auger color: blue color. Color is request.

The devices of driving part for the semitrailer is as below.
The sterna of Front wing of the beam upper: 8mm; bottom: 10mm(double layers), middle: 8mm; the height of the rear wing is 480mm, W higher strengthen bend type and
Straight beams through, 90# tractor pin, 28T outriggers, 13T FUWA axles*3, 16T braking pads, 12.00R20 rail tires*12, 16×8 pieces spring, 1200mm tool box*1, spare tires frame*1, etc.
The upper parts of bulk feed container is as below.
1, the volume of the bulk feed tank is 66cbm, the feed tanker adopts high quality 4mm thickness carbon steel. There are 4 * auger for the whole vehicle are driven by 4* 5.5KW electronic motors. The top mounted auger is controlled by the hydraulic system, rotating left-right 180°. There are 6 compartments for 6 different feed pellets. The discharging pipe Tilt 60 °, the vertical discharging height is 8.5m. It is needed about 50m to fully discharging.

Chengli Special Automobile Co., Ltd. Is the leading manufacturer and supplier of feed trucks in China. With many years’ development, we Chengli Company can manufacture and sell farm-oriented feed trucks(electronic system discharging or hydraulic system discharging) from 8m3 to 40m3 and 40m3-50m3 animal feed transported semitrailer, etc. And more and more CLW Brand feed trucks have been exported all over the world.

Poultry feed truck is main used for delivering, loading and discharging of feed pellets of different feed factories, large-type poultry farms, and also for transporting some non-corrosive feed pellets, such as pellets from pharmaceutical factory and turnover of grain depots, etc. the feed trucks manufactured by Chengli Special Automobile Co., Ltd. can transporting various feed pellet with the different compartments, the dream transporting vehicles for poultry farms and feed factories. More information, please feel free to contact with Ms. Anita Deng. The hot sale line is 0086 13329899995.
