high quality and best price full landing flatbed wrecker towing vehicle SINOTRUK for sale
Customized full landing flatbed wrecker towing vehicle SINOTURK HOWO brand is finished.
High quality and best price full-landed flatbed towing truck HOWO for sale
High quality customized full landing wrecker towing truck for sale
Customized SINO TRUK HOWO 4*2 LHD 4tons recovery wrecker tow truck adopts SINO TRUK HOWO 4*2 LHD truck chassis, YN4102QBZL 116hp diesel engine, 6 manual speed gearbox, 7.50R16 rail tires, 3800mm wheelbase, power steering +air cut braking, 2.7tons front axle/7.2tons rear axle, etc.
The loading capacity of the flatbed type wrecker tow truck is 4tons, and the length of the flatbed is 5.6m; the width of the flatbed is 2.3m; while the length of the tail plate is 1m, which can be designed and manufactured as hydraulic folded flipping plate. The standard devices of SINO TRUK HOWO 4*2 LHD 4T road wrecker tow truck as below
1, 4 tons loading capacity for the upper part/flatbed
2, 4T hydraulic winch and 20m length wire rope
3, 2.5T loading capacity Retractable Rear Lift Arm (choose to install)
4, auxiliary wheels*1 sets
5, bilateral linkage control valve
6, fully hydraulic flipping plates
7, yellow color alarm light
8, 4* special binding belts
main technical parameters of HOWO 4*2 LHD road towing truck as below
Overall parameters | Product name | SINO TRUK HOWO 4*2 LHD wrecker tow truck |
Manufacturer | Chengli Special Automobile Co., Ltd. | |
Product model | CLW5080TQZZ3 | |
Total mass(kgs) | 8280 | |
Curb mass(kgs) | 5585 | |
Overall dimension (L*W*H)(mm) | 7420×2350×2470 | |
Chassis parameters | Driver cab | SINO TRUK HOWO 2080mm width single row driver cab |
Approach/departure angle(°) | 18/8 | |
Front/rear suspension(mm) | 1160/2460 | |
Axles nos. | 2 | |
Wheelbase(mm) | 3800 | |
Axle load(kgs) | 2870/5410 | |
Max speed(km/h) | 90 | |
Tire specification | 7.50R16 | |
Steel spring | 8/9+5 | |
Front/rear tread(mm) | 1600/1535 | |
Engine model | YN4102QBZL | |
Fuel type | Diesel | |
Emission standard | Euro Ⅲ | |
Gearbox | 6 speed gearbox, manual | |
Upper part parameters | Flatbed dimension(L*W)(mm) | 5600*2300 |
Rear hydraulic flapping plate Length (mm) | 1000 | |
Total flatbed length (mm) | 5600+1000 | |
Hydraulic winch | 4tons | |
Operation way | Bilateral linkage operation | |
Retractable Rear Lift Arm | Choose to install 2.5T | |
Loading capacity of the flatbed | 4tons | |
Wire rope | 20m length | |
Auxiliary wheels | 1 set | |
Special binding belts | 4 sets | |
Yellow color alarm light | Yes |
