The vacuum sewage suction truck is also called sewage truck,vacuum pump sewage truck, sewer vacuum truck, sewer tanker truck, vacuum sewage suction truck, sewage suction tanker truck, etc. It mainly used for sucting, transporting and discharging of feces, sewage, wastes water from septic tanker and sludge from drains. Widely used by municipal environment and sanitation department and residential management.

the septic tanker truck manufactured is as below.
1.Tank can be lifted hydraulically to 40 to 45 degree.Rear door can be opened&closed hydraulically. With full opening design, discharge can be very quick&complete.
2.Overfill system with music horn is equipped to prevent the vacuum pump damage from sewage water into vacuum pump when the tank is full.

3.Super power of vacuum pump, seamless die casted sheel cover, designing for container with high ability of pressure-resistance, double hydraulic jack system, morestrength then cesspit  emptier.

FAW VH single row diver cab

4*2 LHD, RHD optional

3860mm wheelbase

YC4D130-33 yuchai 130hp diesel engine, Euro 3 emission standard

WLY 6+1 gears, manual type

8.25R16 tires*6+1 spare,

Power sterring, air conditioner, etc.

Upper part:

The tanker volume is 9000Liters, adopts high quality 6mm thickness carbon steel material, Reasonable designed anti-wave sheets inside the tanker.

Installed with good quality vacuum pump,install four-way valve dual stainless steel filters.

3, vacuum pipeline with stainless steel filters(avoid impurities into the pump)

4, Shake-resisting pressure gauge of DN100 installed at the position of sewer four-way valve to resisting working environment vibrations and reducing the pulsating effects of medium pressure.

5, DN150 drain-outlet and DN100 suction-inlet

6, the vacuum tanker can be lifting and tipping; the rear door can be opened hydraulically with locking device.

7, wider platforms at two sides of the vacuum tanker, which convenient for discharging sewage suction pipes and other working tools.

More pictures of FAW brand vacuum tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.

HOT SALE! FAW vacuum tanker truck 9,000Liters

Sewage suction truck is a new type of environmental sanitation vehicle which collects and transports sludge and sewage and avoids secondary pollution. It can suck and drain by itself with high speed, large capacity and convenient transportation. It is suitable for collecting and transporting liquid substances such as feces, slurry and crude oil. The suction truck adopts the vacuum pump of the domestic advanced suction truck, which has large suction force and long suction distance. It is especially suitable for suction, loading and discharge of the silt in the sewer, especially for sucking the mud, silt, stone, brick and other large objects in the sewer. More information, please feel free to contact with Ms. Anita Deng, The hot sale line is 0086 13329899995.
