HOT SALE! ISUZU Euro 6 190hp diesel day old chick transporte

HOT SALE! ISUZU Euro 6 190hp diesel day old chick transported van truck for sale

ISUZU brand 700P series day old chick transported truck, adotps high quality 700P single row reserible driver cab with power steering and air conditioner, ISUZU MLD 6 speed gearbox, 5200mm wheelbase, 4HK1-TCG61 Euro 6 190hp diesel engine, 4tons front axle/7tons rear axle, ABS, air cut braking, 235/75R17.5 tires, etc.

The technical parameters of upper part for dongfeng D9 as below

The cold van body dimension of Dongfeng D9 day old chicks transported carrier is 6860*2100*2000 (mm). The interior and exterior of the van box body with fiber reinforced plastics(FRP), and the middle insulation layers of 80mm thickness PU foam. There are sliding windows and waterproof blind-windows. The air will be from the van body floor ventilation

Left and right sides of the van body are with 12 sets 40*40 Mesh Plates for the cold air from the reefer. There are several 320*320 electronic ventilator fans mounted on the truck top and the rear door plate. Folding Shelves are for the two sides van body. Both Two sides of the van body with 5 blind-windows; while top mounted sky-window. Three lines of ventilator Air Ducts mounted on the van floor. The reefer choose high quality China made engine-powered refrigerator( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab). The heating system is selective.

Product name	ISUZU 700P LHD 4*2 day old chick transported truck(CLW5110XCQQ6)
Overall dimension(LWH)(mm)	897022603310	Chick van box dimension(LWH)mm	686021002000 (mm).
Drive type	4*2 LHD	Total mass	10550kgs
Curb mass	5680kgs	Rated mass	4675kgs
Gearbox	ISUZU MLD 6 speed transmission, manual	Tyre specification	235/75R17.5 tires
Power steering	Yes	Front/rear axle	4tons/7tons
Oil braking	Yes	Driver cab	Isuzu 700P single row driver cab with air conditioner and power steering
Engine	4HK1-TCG61	Emission standard	Euro 6
Engine type	Isuzu 190hp diesel engine

Main parameters of chick baby van box body as below

Performance and consumption
Heating system	Watering system	Without, client choose to install
Cooling system	One reefer	USA brand THERMO KING vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab)
Ventilation system	Air duct installed on the floor for air flow	Two/three line as the pictures show
	Blind windows	6 sets of blind windows with sliding doors for the left and right van sides (as the pictures show), *Windows: 62 = 12 windows**
	electronic ventilator fans	6 sets of electronic ventilator fans on van top; 4 sets for the back door. *Electronic fans: 62+4=16 fans**
	Sky-window	Top mounted sky window* 4 sets sky-windows
Dimension
Chick van box body	Length	6860mm
	Width	2100mm
	Height	4675mm
Material	Exterior and interior	High quality with whole skeleton of the SANDWICH plate bonding process. Inner plate use high quality fiberglass and exterior plate with Fiberglass Reinforced Plastic (FRP)
	Middle insulation layer	Middle insulation layer with high quality 80mm PU foam sheets.
Chicks nos.	About 40,000chicks

Day old chick truck is also called baby chick truck, young chicks transported truck. There are several electronic ventilator fans on the top, and the left-right sides with several slidable windows to keep air ventilated. There is cooling reefer, adjusted the temperature freely, suitable for transporting farm poultry, etc.

It is mainly for professional transporting day old chicks, day old ducks, baby goose, flowers, seedlings, etc. a good tools to improve efficiency and reduce transporting cost.

There are ventilation and heating system inside the farm poultry transported truck. There are several electronic ventilator fans (according to the length of the insulation van) on the top for ventilating, assuring offering enough oxygen for the baby young chicks/ducks/ gooses in the van. There are several windows (according to the length of the chick box body) for ventilating, heating, oxygen-offering.

And we can design and installed shelves in the van body.

The poultry transported truck is mounted on the truck chassis, choosing high quality, high strength FRP materials with high-tech Sandwich crafts working.

The advantages of the day old ducks truck are rainproof, dustproof, theft-proof, environmental protection, high efficiency, ventilating, insulation, large loading capacity, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of van truck in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply refrigerated truck, insualtion body van box, cargo van truck, baby chick transported truck, etc. And our CLW brand van truck have been exported to many countries all over the world. More information, please feel free to contact with Ms. Anita.
